| OVERALL SIZE |
|
| Total Length (during transportation) |
9425mm |
| Total Width |
2980mm |
| Total Height (top of boom) |
2970mm |
| Upper Width |
2710mm |
| Total Height (top of cab) |
3040mm |
| Standard Track Width |
600mm |
| Gauge |
2380mm |
| Min. Ground Clearance |
440mm |
| Tail Radius of Gyration |
2710mm |
| Track Ground Length |
3275mm |
| Track Length |
4070mm |
| |
|
| PERFORMANCE PARAMETER |
|
| Machine Weight |
21300KG |
| Bucket Capacity |
0.8-1.1M3 |
| Rated Power |
124KW/2050rpm |
| Walking Speed |
5H.5L/3KM.3H |
| Rotation Speed |
11rpm |
| Climbing Ability |
70% |
| Ground Pressure |
48.6kpa |
| Bucket Digging Force |
150kn |
| Stick Digging Force |
109kn |
