| PERFORMANCE |
| Rated Load |
5000 KG |
| Overall Weight |
16500 KG |
| Rated Bucket Capacity |
3m³ |
| Max. Tractive Force |
168 KN |
| Max. Breakout Force |
≥170 KN |
| Max. Grade Ability |
30℃ |
| Max. Dumping Height |
3142 mm |
| Max. Dumping Reach |
1250 mm |
| Dimension (L x W x H) |
8085 x 2963 x 3463 mm |
| Minimum Turning Radius |
6732 mm |
| ENGINE |
| Model |
Weichai Steyr WD10G220E23 |
| Type |
Straight Line, Water Cooling, Dry Cylinder Liner, Direct Injection |
| No. of Cylinder-Bore/Stroke |
6 - 126×130 mm |
| Rated Power |
162 KW - 2000 RPM |
| Maximum Torque |
860 N.m |
| Min Fuel-Consume Ratio |
≤215 g/Kwh |
| TRANSMISSION SYSTEM |
| Torque Converter |
YJ375 |
| Gearbox Mode |
Power Shift Normally Engaged Straight Gear |
| Gear Shift |
4 Forward Shift, 4 Reverse Shift |
| Maximum Speed |
39 Km/h |
